Schematic Capture
Converting your circuit concept or reference design into a clean, simulation-ready schematic with proper net naming and verified component libraries.
- Tools: Altium / KiCad / Eagle
- Best for: New Product Concepts
18+ Years Design Experience
In-House DFM Review
Precision PCB Design & Layout From Schematic to Signed-Off Gerbers
Our design engineers turn your concept into a manufacturing-ready board — schematic capture, layout, DFM validation, and full documentation handled in-house by the same team that fabricates it.
PCB Design Services
From first schematic to fabrication-ready files — full-cycle design engineering under one roof.
Design Standards & Tools
The software, standards, and delivery formats behind every design we ship.
Design Software
Altium Designer, KiCad, Eagle, OrCAD, EasyEDA,
Max Layer Count Supported
Up to 4 Layers
Impedance Control
± 10% Tolerance
Component Library
50,000+ Verified Footprints
File Delivery
Gerber X2, ODB++, IPC-2581
Review Standard
IPC-2221 / IPC-2152 Compliant
Simulation Support
SI / PI Pre-Layout Analysis
NDA Policy
Available on All Design Projects
From Design Straight Into Fabrication
Every design we create is validated against our own manufacturing line — no handoff friction, no re-engineering.
Our Design Process
01
Requirement Intake
We gather your circuit concept, target specs, and application requirements.
02
Schematic Design
Circuit schematic captured with verified libraries and proper net structure.
03
Component Selection
Parts chosen for availability, cost, and long-term sourcing reliability.
04
Layout & Routing
Placement and copper routing optimized for manufacturability and signal integrity.
05
DFM Verification
Design checked against real fabrication tolerances before sign-off.
06
Client Design Review
Layout walkthrough with you before files are finalized.
07
Final Package Handoff
Gerbers, BOM, and pick-and-place data delivered, ready for production.
Why Design With Us
precision_manufacturing
In-House Fab Integration
Your design is reviewed by the same team that manufactures it, catching fabrication-reality issues most standalone design shops miss.
speed
Fast Turnaround
Most layouts complete in days, not weeks — without cutting corners on DFM validation or documentation quality.
support_agent
Direct Engineer Access
You talk to the person doing the design, not an account-manager relay — faster answers, fewer misunderstandings.
Frequently Asked Questions
Both. We can start from a blank concept, a reference design, or your existing schematic — whatever stage your project is at.
